Rotating baking ensures even coloring without the need for adjusting the pan.
The turntable frame adopts a clutch method, which automatically slips when obstructed, ensuring safety and reliability, and can be easily disassembled and cleaned.
The rear air duct baffle is adjustable, and the air volume can be manually adjusted according to the customer’s product.
99 sets of stored programs and 12 sets of shortcuts.
The inner box adopts full welding technology and is equipped with 6mm thick 304 heat storage iron to store more heat, greatly improving the expansion strength and fullness of the product.
Using high-quality 80mm thick aluminum silicate insulation material, maximising the insulation effect.
Adopting double-layer large glass doors, with great perspective effect, it is convenient to observe the baking progress.
The inner box is made of 1.2mm 430 stainless steel, the front of the outer box is made of 1.2mm 430 stainless steel, and the other surfaces are made of 1.2mm galvanized sheet.
| Voltage |
380V(3P+N+PE) |
| Power |
9.5 kW |
| Weight |
235KG |
| Temperature Range |
Room Temp~300℃ |
| Time |
0~99 mins |
| Tray Quantity |
5 |
| Tray Size |
400mm*600mm Euro Size |
| Bracket Spacing |
90mm |
| Product Dimension |
|
| Length |
950mm |
| Width |
1300mm |
| Height |
1790mm |
| Internal Dimension |
|
| Length |
800mm |
| Width |
800mm |
| Height |
550mm |
| Packing Dimension |
|
| Length |
1060mm |
| Width |
1355mm |
| Height |
1890mm |
| Gross Weight |
303KG |
